HPE Apollo 4200 Gen10 48 Server Chassis | P07246-B21

The HPE Apollo 4200 Gen10 Server offers an architecture optimized for Big Data Analytics, Software-Defined Storage, backup and archive, and other data storage-intensive workloads. It's unique, easily serviceable 2U design saves data center space with up to 28 LFF or 54 SFF hot plug drives. It delivers accelerated performance with superior bandwidth and balanced architecture, Intel Xeon Processors, and NVMe-connected SSDs.

The focus on security extends from FIPS 140-2 Level 1 validated storage controllers down to the system silicon level, taking full advantage of HPE innovations in firmware protection, malware detection, and recovery. With HPE GreenLake Flex Capacity and HPE Financial Services, you can combine the economic agility benefits of consumption-based IT with the performance and security of on-premise.

What's New for Apollo 4200 Gen10

• Supports Intel Xeon Scalable Processor Family.
• Optional rear storage upgrade to support up to 6 SFF NVMe solid state drives (SSDs).
• Higher bandwidth and more balanced system architecture design, and without trade-offs between drive bays and I/O slots.
• Firmware-level security and optional chassis intrusion options.
• Flexible HPE Smart Array Gen10 Controllers support and encryption features to meet different performance requirements for storage solutions.
• Support for daisy-chaining of out-of-band management network ports.

Ultra-dense and Rack Scale

Highest data storage density in a unique, easier to service 2U standard rack depth chassis.

Up to 28 Large Form Factor (LFF) or 54 Small Form Factor (SFF) hot-plug drives and without I/O compromises. Up to 392 TB in 2U space with 14 TB LFF drives support for the LFF models.

Support for daisy-chaining of out of band management network ports for 95% reduction in management network port consumption per 42U rack.
